PEP 6000 DataSheet

Misc functionality

TECHNICAL DATA

Walking plane maximum height	6.00 m
Max Weight (including 60 kg of gear)	200 kg
Maximum number of lifting operators	2
Max wind speed allowed	20,58 m/s
Maximum inclination allowed	0°
Normal operating power supply	Internal combustion engine
Electric system power voltage	12 V
Operating pressure of the oleodinamic system	120 bar
Emergency power supply	Hand pump
Pondered equivalent continuous acoustic pressure level	< 70 dBA

REFERENCE NORMS

The referring normatives used for the designing and manufacturing of the PEP 6000 lifting platform is the European-norm EN 1915 (Aircraft ground support equipment).

DEVICES

The lifting platform is furnished with:
• stabilizers control panel;
• Control panel on the working platform.

SAFETY DEVICES

Platform is conform with actual norms of health and safety.
Use of platform is only allowed when Parking Brake is set and stabilizers completely extended.
Automatic engine shut down in case of accidental intent to insert gear with stabilizers extended.
Platform commands only with "Present Hand" Hand Pump is available in case of failure.
